FMF Technology - Simultaneous Multi-Frequency for any soil, wet or dry.
Ultra Lightweight - Just 830g fully equipped (only 710g without remote)
Set up in two steps - Power ON > Choose program
Highly intuitive remote - Clean interface, 3 preloaded programs and 3 customizable slots (6 of each ICON-X)
Wireless & Latency-free - Remote, coil, and headset communicate instantly using XP’s protocol.
Advanced Audio Option - PWM, Square. 2,3 and 5 tones or Full Tones. You can choose from the options which combine various audio types for the ultimate audio experience.
XP Go Terrain App - Record finds and track routes via smartphone GPS.
Waterproof up to 5m - A true underwater experience with its dedicated bone conduction headphones.
| Brand | XP |
|---|---|
| Detector Type | Simultanious Multi Frequency and Motion |
| Waterproof Coil | Yes |
| Weatherproof | Yes |
| Prospecting | General |
| Frequency modes | Multi Frequency |
| Frequency | kHz |
| Coil Size | 11" |
| Changeable Coil | Yes |
| Wireless Coil | Yes |
| Wireless Pin Pointer | Supported |
| Wireless Headphones | Supported |
| Audio Socket | Small Jack (3.5 mm) |
| Volume Control | Yes |
| Built-In Battery | Yes |
| Battery Type | Lithium-ion (Li-Ion) |
| Battery Included | Yes |
| Display | Yes |
| Display Backlight | Yes |
| PinPoint Mode | No |
| Target Depth | No |
| Target I.D. | No |
| Included | Stem, Coil, Coil Cover, Headphones, Remote, Charger Lead |
| Warranty | 5 Years |
| Weight (kg) | 0.845000 |
XP ICON & ICON-X Metal Detectors
Powerful. Simple.
Versatile. Affordable.
Two advanced wireless detectors powered by FMF® technology. Desigened to adapt. Built to perform.
Meet the new XP ICON and ICON-X, two advanced wireless detectors designed to make the XP experience accessible to more users. Powered by FMF® technology, both models deliver precision, versatility, and user-friendly performance. Pick the one that best matches your terrain, your detecting style, and your ambitions.
Available options:
| ICON | ICON X |
|
ICON with Remote control, ICON 11" FMF Coil, S-Telescopic Lite Stem, aluminium middle stem and carbon filament lower stem. ICON with Remote control, ICON 11" FMF Coil, WSA ST Headphones, S-Telescopic Lite Stem, aluminium middle stem and carbon filament lower stem. |
ICON X with Remote control, ICON 11" FMF Coil, S-Telescopic Lite Stem, Carbon Weave middle stem and carbon filament lower stem. ICON X with Remote control, ICON 11" FMF Coil, WSA ST Headphones, S-Telescopic Lite Stem Carbon Weave middle stem and carbon filament lower stem. |
DOMINATE THE BEACH
From dry sand to wet saltwater areas, the XP ICON adjusts seamlessly to changing beach conditions. It delivers excellent stability, precise target identification, and strong sensitivity—whatever the tide brings.
PURE DETECTION
Iron-heavy ground won’t hold you back. With intelligent discrimination, adjustable reactivity, and iron volume control, the XP ICON helps you isolate valuable targets even in the most challenging soils.
Highlights
Designed to Detect. Built to Explore
FMF® Technology
Simultaneous FMF® Multi-Frequency with automatic and manual frequency shift.
Ultra Lightweight
Lightweight build designed for long detecting sessions with minimal fatigue.
Set Up in Two Steps
Power ON → choose your program. That's it.
Wireless & Latency Free
Instant communication between coil, remote and headset.
Signal Stability
Stable performance in all terrains and conditions.
XP Go Terrain App
Track finds and log routes using GPS connectivity.
Compare ICON vs ICON X
|
Feature |
ICON |
ICON X |
|
Detection Frequencies |
Simultaneous Multi-frequencies (40dBµA/m at 10m) – Automatic and manual frequency shift 2 mono frequencies (4 and 14 kHz) |
Simultaneous Multi-frequencies (40dBµA/m at 10m) – Automatic and manual frequency shift 3 mono frequencies (4, 14 and 28 kHz) |
|
Sensitivity |
25 levels |
25 levels |
|
Audio Types |
PWM and SQUARE with Stereo Audio Morphing 3 settings with standard audio curve |
PWM and SQUARE with Stereo Audio Morphing 6 settings (extra enhanced audio curve) |
|
Audio Volume |
10 levels for each output |
10 levels for each output |
|
Reactivity |
5 levels (1/2/3/4/5) |
7 levels (0/1/2/3/4/5/6) |
|
Iron Volume |
11 levels |
11 levels |
|
Multi Tones |
Pitch, 2, 3, 5 tons, Full Tones |
Pitch, 2, 3, 5 tons, Full Tones |
|
Ground Effects |
Grab, Tracking, Mode Standard and Pro |
Grab, Tracking, Mode Standard and Pro |
|
Multi-Notch |
Yes – 28 segments |
Yes – 28 segments |
|
Static Mode |
Yes – Audio and visual |
Yes – Audio and visual |
|
Discrimination |
Audio and visual rejection of ferrous caps – Automatic silencer – All-metal mode Resolution: 1 point (ferrous zone) |
Audio and visual rejection of ferrous caps – Automatic silencer – All-metal mode Resolution: 0.5 point (ferrous zone) |
|
Programs |
3 factory + 3 users |
6 factory + 6 users |
|
Audio Outputs |
Wireless headphones + automatic selection (speaker, wired, bone conduction headphones) |
Wireless headphones + automatic selection (speaker, wired, bone conduction headphones) |
|
Connectivity |
Pinpointer MI-6 and Go Terrain app |
Pinpointer MI-6 and Go Terrain app |
|
Feature |
Specification |
|
Display |
Sun-readable LCD with adjustable low-power backlight |
|
Software Update |
Yes, via USB / Internet connection |
|
Optional Wireless Headphones |
Compatible with the DEUS II FMF ecosystem (WSA ST, WSA ST XL, etc.) |
|
Optional Wireless Coils |
Compatible with DEUS II FMF ecosystem coils: D22FMF (22.5 cm), DELLFMFHP (24–13 cm HF2), D28FMF (28 cm), D3428FMF (34–28 cm) |
|
Stem |
Fully telescopic S-shaped stem: 58 cm collapsed / 130 cm extended |
|
Batteries |
Remote and Headphones: 365 mAh / Coil: 700 mAh |
|
Battery Life (remote) |
~11h depending on audio output |
|
Battery Life (coil) |
~11h |
|
Charging Time |
~3h |
|
Total Weight |
~830 g for ICON X (~710 g without remote) |
|
Stem Weight |
~260 g (S-Telescopic lite carbon) |
|
Remote Weight (with batteries) |
~110 g |
|
Headphone Weight (with batteries) |
WSA ST: ~72 g / WSA ST XL: ~250 g |
|
Coil Weight |
ICON 28 cm: ~370 g (coil cover included) |
|
Operating & Charging Temp |
From 0 to +40°C |
|
Recommended Storage Temp |
25°C |
|
Waterproofing |
IP68 – 5 m – 30 min (BH-02 bone conduction headphones and waveguide required) |
|
Warranty |
5 years parts and labour + 5 years optional Batteries and accessories: 2 years |
|
Patents |
US7940049 B2 – EP1990658 B1 – US 12, 24B, 113 B2 – EP 4377722 and patents pending |
As a brand committed to responsible innovation, XP is proud to offer products certified with the Longtime® label, recognising durability, reparability and long-term support. Your detector is built to last - because real adventure deserves real reliability.
